BL-308A Circuit Breaker Tester

Introduction

    BL-308A Circuit breaker analyzer is a special instrument developed by our company in order to meet the needs of on-site test of high voltage switch. The MCU is the core sampling, processing and output, the main instrument is characterized by the use of man-machine dialogue mode, English characters display results and print output, has the advantages of multifunction, intelligent, accurate data, strong anti-interference, simple operation, small volume, light weight, beautiful appearance. Circuit breaker analyzer is suitable for various indoor and outdoor less oil, oil switch, vacuum switch, six sulfur hexafluoride switch dynamicacteristics test.

Technical Specifications

Characteristics

    ● The instrument can automatically identify the fracture opening and closing state, and according to the reference state corresponding to the fracture tip and operation.

    ● Independent 6 fracture, can detect and indicate the connection state of the fracture, facilitate the user to check the wiring.

    ● The machine can store 100 groups of test results.

    ● Large screen LCD (320×240) LCD display, advanced gray screen, in the sun is not black reflective, graphic and English characters menu operation, user-friendly menu interface, easy to operate.

    ● Instrument has powerful function of graphic analysis, and the waveform and measurement data are displayed on the same screen;

    ● The utility model has the function of time delay protection, and the coil voltage can be automatically cut off after the circuit breaker is operated;

    ● The instrument do electric test and manual test.

    ● For high and low voltage test, automatically find the lowest score or closing voltage.

    ● Reclosing test, can be divided into points, points, points and parameters, can test the parameter for open-close ,close-open ,close-open-close.
